Product model

HN3160P21D2M

G.V.W

16 ton

Drive model

6×2

Payload

8 ton

Engine model

WD615.56

Engine Max. Power (kw/r/min)

193/2200

Engine Emission Standard

Euro II

Transmission brand

Shanxi FAST GEAR

Transmission model

9JS119

Rear Axle(drive axle)-load

13 ton

Front Axle-load

7.5 ton x 2

Steering System

HITACHI

Wheelbase

1850+4250mm

Tire type

Bias/Radial/Radial tubeless

Tire model

11.00-20/11.00R20/11R22.5

Tire number

8+1

Oil Tank Volume

320L

Overall Dimensions(L×W×H)

9680x2495x3450mm

Body steel thickness

Bottom 8mm/ Side 5mm

Body lifting system

Hydraulic central lift

Front overhang / Rear overhang

1370/2210mm

Max. Speed ()

78 km/h
