ZL12

Share This Product:

Main features:

--Originally from Komatsu technology, high reliability and productivity

--Cummins China engine, powerful and reliable

--Torque converter and counter-shaft transmission gearbox are separated independently, higher reliability and easier maintenance

--Driving Axle in Meritor technology

--Fully hydraulic steering system, power shift transmission, easy to operate

--Comfortable operation environment, spacious cabin, Grammer seat,

--Various attachment are available, such as Log clamp, pipe clamp, rock bucket, loose bucket etc. to meet different needs

TECHNICAL SPECIFICATION

Main Technical Data
Bucket Capacity (m3)	0.45
Rated Load ( t )	1.2
Max. Dump Height (mm)	2850
Dump Distance (mm)	790
Max. Break Force (KN)	36
LWH (mm)	490016002550
Operating Weight (t)	2.5
Total Cycling Time (s)	13
Wheel Base (mm)	2100
Tread (mm)	1440
Min. Turn Radius (mm)	3400
Engine
Model	CHANGCHAI QC2105
Rated Power (kw) /Speed (rpm)	24/ 2200
Fuel	0 or -10 light diesel
Tire Size	8.25-16
Note: Materials and specifications are subject to change without notice.

Main Technical Data
Bucket Capacity (m3)	0.45
Rated Load ( t )	1.2
Max. Dump Height (mm)	2850
Dump Distance (mm)	790
Max. Break Force (KN)	36
LWH (mm)	490016002550
Operating Weight (t)	2.5
Total Cycling Time (s)	13
Wheel Base (mm)	2100
Tread (mm)	1440
Min. Turn Radius (mm)	3400
Engine
Model	CHANGCHAI QC2105
Rated Power (kw) /Speed (rpm)	24/ 2200
Fuel	0 or -10 light diesel
Tire Size	8.25-16
Note: Materials and specifications are subject to change without notice.
